项目lem\型号Model
|
X(S)N-3X32 |
X(S)N-10X32 |
X(S)N-20X32 |
X(S)N-35X30 |
X(S)N-55X30 |
X(S)N-75X30 |
X(S)N-110X30 |
X(S)N-150X30 |
|
捏炼总容积
Total Volume of kneading chamber |
L |
8 |
25 |
45 |
75 |
125 |
180 |
250 |
325 |
|
密炼总容积
Total Volume of mixing chamber |
L |
3 |
10 |
20 |
35 |
55 |
75 |
110 |
150 |
|
主驱动电机功率
Driving motor power |
KW |
5.5 |
15 |
30 |
55 |
75 |
110 |
185 |
220 |
翻转电机功率
Tipping motor power |
KW |
0.55 |
1.1 |
1.5 |
2.2 |
3.0 |
4.0 |
5.5 |
5.5 |
|
|
|
135 |
140° |
140° |
140° |
140° |
140° |
140° |
140° |
|
转子轴转速（前/后)(front/back)
Rotational speed of the fotor |
r/min |
0~60,32/24.5 |
30/23.5 |
30/25 |
30/24.5 |
30/24.5 |
30/24.5 |
30/24.5 |
30/24.5 |
压缩空气工作压力
Flow rate of compressed air |
Mpa |
0.5-0.8 |
0.5-0.8 |
0.5-0.8 |
0.5-0.8 |
0.6-0.8 |
0.6-0.8 |
0.6-0.8 |
0.6-0.8 |
压缩空气流量
Flow rate of compressed air |
m3/min |
≥0.3 |
≥0.5 |
≥0.7 |
≥0.9 |
≥1.0 |
≥1.0 |
≥1.5 |
≥1.5 |
|
冷却水压力（炼胶）(rubber mixing) Pressure of Cooling water |
Mpa |
0.2-0.4 |
0.2-0.4 |
0.2-0.4 |
0.3-0.4 |
0.3-0.4 |
0.3-0.4 |
0.3-0.4 |
0.3-0.4 |
加热蒸汽压力（炼塑）(Plastication)
Pressure of heated steam |
Mpa |
0.5-0.8 |
0.5-0.8 |
0.5-0.8 |
0.5-0.8 |
0.5-0.8 |
0.5-0.8 |
0.5-0.8 |
0.5-0.8 |
|
|
L |
MM |
1660 |
2580 |
2630 |
3200 |
3360 |
3760 |
4075 |
4200 |
|
W |
960 |
1300 |
1520 |
1900 |
1950 |
2143 |
2712 |
3200 |
|
H |
1750 |
2280 |
2550 |
2945 |
3050 |
3135 |
3580 |
4000 |
|
|
kg |
2000 |
3300 |
4500 |
6500 |
7200 |
10000 |
14500 |
19500 |
